1PCS ka300 70-470-5um High Precision Linear Encoder Grating Ruler Glass Optical Ruler Machine Tool Digital Display(KA300-320mm-5um)

1PCS ka300 70-470-5um High Precision Linear Encoder Grating Ruler Glass Optical Ruler Machine Tool Digital DisplayProduct Brief:KA-300 grating ruler is a kind of grating ruler which is widely used. It has reasonable structure,The shape design is beautiful, good rigidity, can meet the majority of general machine tool users use, use longDegree in 70~1020mm.1. technical parameters1.1, pitch:1.2, resolution:1.3, accuracy:1.4, range:0.02 mm (50 line /mm)5 um, 1 um, 0.5um+ 3 + 5, M + 15, m m/m (20 + 0.1 C)30~3000mm1.5, moving speed: high speed ruler 120 m/min (need to be customized)Ordinary ruler 60m/min1.6, power supply:+5V + 5%, 80mA1.7, the length of the cable: Standard 3M 1.8, working temperature: 0~45Model Number : KA300-5um-70-470Product Name: : grating ruler linear encodModel: : KA300-5umMeasuring distance: : 70mm-1020mmResolution: : 0.005mmPitch: : 0.02mmVoltage: : DC5VSignal wire length: : 3M metal hoseOutput signal: : TTLMoving speed: : 60 m / minOperating temperature: : 0-45

• Wide Operating Temperature:Function reliably in a range of 0-45℃, suitable for various industrial environments.
• Durable Metal Hose:Equipped with a 3M metal hose, the encoder withstands wear and tear in demanding settings.
• High-Speed Operation:Enjoy swift measurements with a moving speed of up to 60m/min, optimizing workflow efficiency.
• Glass Encoder|Linear Encoder|High Precision Resolution:Achieve ultra-fine measurements with a 0.005mm resolution, ideal for intricate machine tool calibrations.
• Extended Measuring Range:Measure distances from 70mm to 1020mm with ease, catering to diverse industrial applications.
